Sistema Vent^®

Sistema Vent^®:
a safety masterpiece.

With the Sistema Vent^® for the implementation of ventilated facades, Ganmar wants to emphasize the use of natural stone as an architectural element, in both new buildings and old plaster facades to which the new coating can be applied without having to demolish anything.

All the facets
of beauty.

The Sistema Vent^® gives the designer a wide range of materials to choose from and a structure that can be perfectly integrated with the continuous facade of the windows.

This represents an innovative solution not only for important complexes but also for small buildings.

Go to references

The coupling system that guarantees the ultimate fastening.

The Ganmar technology is able to create particularly light covering panels thanks to a width that reaches a minimum of 16/17 mm.
Another distinctive feature is given by the installation of the panels through an innovative mechanical wall-anchoring system that allows for a practical and safe laying.
The mechanical anchoring, with the tassels inserted directly into the stone, gives unaltered grip guarantee.

Data sheet

Technical video

Sistema Vent^® | NO FIRE:

the new frontier of safety for ventilated facades.

The Sistema Vent^® | NO FIRE, an evolution of the well-established Sistema Vent^® for ventilated façades, combines aesthetics, functionality and maximum safety.

Il Sistema Vent^® | NO FIRE, un’evoluzione del consolidato Sistema Vent^® per facciate ventilate, unisce estetica, funzionalità e massima sicurezza.

The novelty?

A glue-reinforced, specially woven technical fabric. The fabric replaces the classic Sistema Vent^® panel, maintaining the A2-s1-d0 fire reaction class and guaranteeing high safety standards with lighter and more flexible panels.

With the Sistema Vent^® | NO FIRE, Ganmar offers designers a complete solution with broad creative possibilities thanks to the use of natural and reconstituted stone as the protagonist. The undercut guarantees excellent sealing performance, making it the ideal choice for public, residential and commercial building facades.

Con il Sistema Vent^® | NO FIRE, Ganmar offre ai progettisti una soluzione completa dalle ampie possibilità creative grazie all’uso della pietra naturale e ricomposta come protagonista. L’aggancio sottosquadro garantisce ottime prestazioni di tenuta, rendendolo la scelta ideale per facciate di edifici pubblici, residenziali e commerciali.

Composition of the Sistema Vent^® | NO FIRE

Wall
Thermal break
Brackets and wall mounting screws
Panel for thermal insulation
Vertical bars with fastening screws
Horizontal bars with screws fastening to the structure
Horizontal bars with screws fastening to the coating
Woven technical fabric + glue
Coating

Data sheet Technical video

1) Dowel; 2) Woven technical fabric; 3) Glue; 4) Coating

Advantages of the Sistema Vent^® | NO FIRE

Fully fireproof and self-extinguishing system: unprecedented fire resistance, certified to the highest standards (fire reaction class A2-s1-d0).
Simplified inspection and maintenance: access to the systems is easy, making the system also ideal for work on existing buildings and renovation of old constructions.
Extreme lightness: Ganmar technology allows the creation of thin, light and strong ‘packages’ with minimum thicknesses of 16/17 mm.
Easy installation: mechanical anchoring system, with inserts directly into the stone, for practical, safe and durable installation.
Architectural versatility: wide choice of materials, shapes and sizes for projects of all scales. Ideal for public, residential and commercial building facades, even of small dimensions.
Ventilation: a ventilation gap is created between the cladding and the insulation, thus drastically reducing the passage of heat, resulting in optimal thermal performance.
